Acute pancreatitis as a complication of trans-arterial chemoembolization of hepatocellular cancer—case report and review of literature

Introduction

Hepatocellular carcinoma (HCC) is the fifth most common malignancy in the world and the leading cause of cancer-related deaths worldwide (1). Prognosis is typically poor because many patients are burdened with unresectable tumors (2). Well differentiated HCC is mostly dependent on the hepatic artery for blood supply and it is through this characteristic that transarterial chemoembolization (TACE) procedure is used as an effective palliative treatment for HCC. The procedure is performed by injecting drug eluting beads loaded with chemotherapy agent into the vasculature supplying the HCC which serves a dual purpose of blocking the blood supply and targeting delivery of the chemotherapeutic agent to the tumor. Complications of TACE can result from inadvertent embolization of arteries supplying the liver, gallbladder, stomach and pancreas. Here we present a patient with HCC who developed a rare complication of acute pancreatitis following TACE procedure, likely owing to his variant arterial anatomy.

Case presentation

A 65-year-old Caucasian male with history of chronic hepatitis C and cirrhosis was diagnosed with multifocal HCC with a dominant lesion in the medial left lobe of the liver. TACE was performed via the right trans-femoral approach. Aortogram, superior mesenteric arteriogram and celiac artery (CA) injections were performed. Celiac arteriogram and subsequent selective arteriogram of the common hepatic artery (CHA) showed variant arterial anatomy with the middle hepatic artery (MHA) arising directly from the gastroduodenal artery (GDA) in close proximity to the origin of the superior pancreatic artery (Figure 1). Super selective catheterization of the MHA (supplying the medial segment of left hepatic lobe) was performed and this was found to be supplying the suspected lesion (Figure 2). Embolization was carried using 70–150 microns microsphere beads (LC Bead M1, BTG, West Conshohocken, PA,USA) loaded with 50 mg of doxorubicin and lipiodol. Subsequently, the lateral segment of left hepatic artery and the right hepatic artery were also embolized using 100–300 microns beads loaded with 50 mg of doxorubicin along with 3 mL of lipidil (Guerbet, Bloomington, IN, USA). The patient was administered prophylactic antibiotics including cefazolin and metronidazole in the immediate pre and post procedure period per protocol.

Figure 1 Hepatic artery proper injection. CHA (A); HAP (B); LHA (C); RHA (D); variant anatomy present where MHA (E) arises directly GDA (F). Note the adjacent origin of superior pancreaticoduodenal artery (G). CHA, common hepatic artery; HAP, hepatic artery proper; LHA, left hepatic artery; RHA, right hepatic artery; MHA, middle hepatic artery; GDA, gastroduodenal artery.

Figure 2 Middle hepatic artery injection. Microcatheter is positioned in the MHA during early injection (A). Delayed imaging at slightly higher magnification shows hyperemia consistent with tumor vasculature (B). Chemoembolization was carried from this position as well as the LHA. MHA, middle hepatic artery; LHA, left hepatic artery.

Patient developed significant epigastric pain within 24 hours of TACE procedure. His CBC showed an elevated WBC count of 15.4 t/c mm. Serum amylase and lipase levels were 400 (ref: 28–100) and 3,809 (ref: 73–383) U/L respectively. His liver function tests showed moderate elevation of serum AST and ALT at 314 (ref: 9–14) and 168 (ref: 17–63) IU/L respectively. Serum alkaline phosphatase and total bilirubin were normal. His right upper quadrant ultrasound did not show gallstones or biliary dilation. Computer tomography scan of the abdomen performed without contrast showed new finding of enlarged head of the pancreas with peri-pancreatic fat stranding consistent with acute pancreatitis (Figure 3). A diagnosis of TACE induced acute pancreatitis was made and patient was treated conservatively. His course of hospitalization was uneventful and he was discharged 72 hours later, in a stable condition. He appeared well 4 weeks after discharge, without further complications. He was subsequently treated again 5 months later to the same artery with the same reagents but utilizing a special micro catheter designed to act as a one way valve during bead delivery to prevent reflux (Surefire Medical, Westminster, CO, USA). The patient tolerated this procedure well and was discharged the next day without any signs of complication.

Figure 3 Non-contrast CT scan 24 hours post TACE shows enlargement of pancreatic head and adjacent fat stranding consistent with pancreatitis. TACE, transarterial chemoembolization.

Discussion

TACE is a common procedure used to treat patients with non-resectable HCC. The therapeutic effect is based on the differential arterial supply of HCC by the hepatic artery while the rest of the liver parenchyma is usually supplied >70% by the portal vein. TACE is used to super-selectively block the arterial supply of the tumor without deleterious effect on rest of the liver. Drug eluting beads coated with doxorubicin is the most common chemotherapeutic agent used for chemo-embolization.

It is imperative for interventional radiologists involved in performing TACE be aware of the anatomical variation of the hepatic arterial circulation to prevent inadvertent embolization and complications. The intra-abdominal portion of aorta most commonly gives rise to three main anteriorly directed branches before its bifurcation. They include the CA, superior mesenteric artery (SMA) and the inferior mesenteric artery (IMA). CHA arises from CA. CHA gives rise to hepatic artery proper (HAP), right gastric artery (RGA) and GDA. Recently, Sureka et al. conducted a retrospective study of 600 subjects to study the variations in hepatic arterial circulation using multidetector CT (MDCT) scan (3). The left hepatic artery (LHA) and right hepatic artery (RHA) originated from HAP in 80% of the cases. The MHA originated from LHA or RHA in 69% of cases. Unusual variations included origin of CHA from SMA or aorta, origin of RHA from SMA, CA or aorta and origin of LHA from LGA or aorta. MHA rarely originated from CHA or an accessory hepatic artery. GDA originated from CHA in 98% while directly originating from the CA, RHA or LHA in less than 2% of cases.

Acute pancreatitis is a rare complication of TACE. The proposed mechanism involves regurgitation of the embolic beads from the hepatic artery into an artery supplying the pancreas, especially the GDA (4), resulting in ischemia of the pancreas. It is important to note that the head of the pancreas is particularly susceptible to ischemic injury since the arteries supplying it (pancreaticoduodenal arcades anterior and posterior) are terminal arteries. The rest of the pancreas, which is richly supplied by branches of SMA, is rarely the primary site of injury (4). The incidence of acute pancreatitis following TACE ranges from 1.7% to 15.2% (4,5). Acute pancreatitis can develop within 24 hours to up to 15 days after TACE procedure (6,7). The severity can range from mild (4) to necrotizing pancreatitis (6-12). In the largest study by López-Benítez et al., evaluating risk factors for acute pancreatitis following liver embolization (bland or chemotherapeutic), volume of embolic microspheres and use of carboplatin were most significantly associated with TACE induced pancreatitis (4). Carboplatin, when given systemically has been associated with acute pancreatitis (13). Anatomical variations of hepatic artery or arterio-venous fistulae, size of microspheres or use of lipiodol, were not associated with post TACE acute pancreatitis.

Although prior authors have stated anatomic variation is not necessarily associated with pancreatitis following TACE, it is likely that specific variation presented here is so rare that it would be difficult to have a study that was powered to truly detect whether anatomic variations had a significant impact on pancreatitis post-TACE. It stands to reason that larger volumes administered lead to increased stasis in the target artery and thus increased likelihood of reflux of embolic material with resultant non-target embolization. Non-target embolization of pancreatic arterial supply is the likely culprit for pancreatitis, regardless of anatomy. In our case, a reasonable conjecture is that the close proximity of the superior pancreaticoduodenal artery to the target artery makes even a small amount of reflux a risky proposition. As with every case, embolization was carried out under direct visualization watching for stasis in of flow in the artery and stopping before any reflux was identified. It seems likely, though, that a small amount of material refluxed undetected. Even a small amount of reflux when combined with the anatomic variant could have contributed to the development of pancreatitis.

The most common adverse effect of TACE is post-embolization syndrome and occurs in 60–80% of patients (14). This comprises symptoms of abdominal pain, fever and ileus as a result of local cytotoxicity and tumor ischemia. Other immediate complications include chemical cholecystitis (5), and tumor rupture (15). As most of these complications present with post procedure abdominal pain, laboratory investigations and further imaging is often necessary to determine the etiology of the abdominal pain. Long term complications of TACE include gastric ulcer (14), liver abscess (16) and biliary strictures (17). Rarely, arterio-venous shunts result in systemic complications including pulmonary embolization (18) and contrast induced acute renal failure (19). In a study by Xia et al., the total incidence of a severe complication from TACE of the liver was 2.68% (18). Obtaining a good arteriogram and identification of anatomical variations and arterio-venous shunts combined with targeted chemo-embolization may avoid most of TACE induced complications.

Conclusions

We report a case of acute pancreatitis that developed as a complication of TACE procedure that was performed for HCC. Even though, a super selective catheterization of the MHA supplying the tumor in the medial left lobe was achieved, the anatomical variation of this artery arising directly from the GDA, instead of from the proper hepatic artery, may have resulted in reflux of the embolic beads into the GDA and acute pancreatitis.

Acknowledgements

None.

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Written informed consent was obtained from the patient for publication of this manuscript and any accompanying images.
