Rare postoperative hemorrhage after robotic-assisted pancreatoduodenectomy for pancreatic head cancer: a case report

Introduction

Pancreatic cancer is one of the most lethal malignancies and is associated with very poor overall survival (1). Surgery remains the only option for the possibility of cure for patients with localized pancreatic cancer. Pancreatoduodenectomy (PD) is the major surgical option for pancreatic head cancers. With the development of laparoscopic surgical skills, internal closure devices, and energy systems, robotic-assisted pancreatoduodenectomy (RAPD) can be safely performed in well-selected patients by well-trained teams with extensive experience in open PD (2,3). The perioperative mortality of pancreatic surgery, especially in high-volume centers, has decreased dramatically to less than 5% in the last two decades (4). However, the rate of the occurrence of postoperative complications remains high (5). The most common complications of PD are postoperative infections, delayed gastric emptying, hemorrhage, and anastomotic insufficiencies (pancreatic, biliary, gastric/duodenal, and enteral) (6,7). Among patients who had undergone PD, approximately 2–10% develop post-pancreatectomy hemorrhage (PPH), a life-threatening complication with the reported mortality rate of 20–50% (8,9). Here, we report a male patient who experienced PPH with a very rare cause after RAPD. We present the following article in accordance with the CARE reporting checklist. Available at http://dx.doi.org/10.21037/jgo-20-207.

Case presentation

Chief complaints

A 67-year-old man presenting with appetite loss, general fatigue, and painless jaundice was admitted to our ward.

History of past illness

The patient had no previous noteworthy medical history.

Personal and family history

The patient did not smoke tobacco or consume alcohol. Relevant personal or family history did not exist.

Physical examination

The patient had yellow skin and sclera. The patient’s abdomen was soft and flat without spontaneous pain or tenderness.

Laboratory examinations

The patient’s laboratory results were as follows: hemoglobin 13.5 g/dL, total bilirubin 216.6 µmol/L, direct bilirubin 191.5 µmol/L, albumin 34.6 g/L, and immunoglobulin G 4 0.901 g/L. Tumor markers were normal except for an elevated level of carbohydrate antigen 19-9 (50 U/mL).

Imaging examinations

Computed tomography (CT) scan revealed a 17-mm wide low-density area in the uncinate process of the pancreas (Figure 1A). Magnetic resonance cholangiopancreatography showed the dilation of bile and pancreatic ducts (Figure 1B).

Figure 1 Imaging findings. (A) Preoperative computed tomography showed a 17-mm wide low-density area in the uncinate process of the pancreas; (B) magnetic resonance cholangiopancreatography revealed the dilatation of intrahepatic and extrahepatic bile ducts and pancreatic duct.

Treatment

RAPD was performed by using the da Vinci Model S Surgical System (Intuitive Surgical, Sunnyvale, CA, USA) (Figure 2A). Digestive tract reconstruction was performed via Child’s method. The order of anastomosis was pancreaticojejunostomy, hepaticojejunostomy, and gastrojejunostomy. Gastrointestinal anastomosis reconstruction was conducted behind the colon. Pancreaticojejunostomy was performed via the pancreatic duct to the jejunal mucosa. Biliary anastomosis was continuously sutured with the absorbable barbed wire, and a T tube was not placed in the anastomosis. Gastrointestinal anastomosis was carried out with a linear cutting occluder with side-to-side anastomosis. After the surgery, the patient was admitted to the inpatient ward.

Figure 2 Intraoperative findings and gastroscopic examination. (A) Intraoperative findings for robotic-assisted pancreatoduodenectomy; (B) gastroscopic examination showed a large amount of hematocele and congestive and edematous intestine in the stomach.

On postoperative days (PODs) 1 to 3, the patient was in stable condition without increased amylase in exudate fluid from drainage. On POD 4, the patient intermittently vomited gastric content. On PODs 5 and 6, the patient vomited blood, and bloody fluid was observed in the drainage. Epigastric paroxysmal abdominal pain existed but lacked peritonitis signs. The CT angiography of the superior mesenteric artery was immediately performed, but the hemorrhage source could not be confirmed. The patient experienced continuous blood vomiting and declined hemoglobin. Emergent gastroscopic examination was performed, and a large amount of hematocele was found in the stomach (Figure 2B). Congestive and edematous intestine was present in the stomach (Figure 2B).

On POD 6, emergency operation was performed. The output jejunal loop was found to have intussuscepted in the stomach (Figure 3A). After gastrotomy, a long section of the small intestine was found inside the stomach (Figure 3B). Reconstruction after partial gastrectomy and partial intestinal resection was performed.

Figure 3 Emergency operation. (A) Output jejunal loop was found intussuscepted in the stomach; (B) long section of small intestine was found inside the stomach.

Final diagnosis

Pancreatic ductal adenocarcinoma (T2N0M0, stage I B).

Outcome and follow-up

After exploratory laparotomy, the patient recovered well and was discharged 10 days after operation. Hemorrhage was no longer observed during the follow-up. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this study and any accompanying images.

Discussion

PD is a standard procedure for pancreatic head cancer. Considerable progress has been made in the safety of PD due to the ingenuity of surgeons and advances in surgical instruments. Nonetheless, the occurrence rate of postoperative complications is high.

PPH is the most common and dreaded complication after PD and is associated with mortality rates of as high as 21% (9). A recent study reported that 3.8% of 105 patients who underwent robotic PD experienced PPH (10). Another recent study reported by Shi et al. showed postoperative bleeding rates of 4.3% after RAPD (11). The International Study Group for Pancreatic Surgery divided PPH cases into early hemorrhage occurring within 24 h after operation and late hemorrhage beyond 24 h after operation to facilitate the standardized reporting and study of this complication (8). Delayed PPH is among the most devastating postoperative complications for PD. A review of a prospective database of 1,669 consecutive pancreatic resections showed that the mortality rate among patients presenting with delayed hemorrhage is nearly 50% (12).

The diagnosis of PPH may be confirmed via upper gastrointestinal endoscopy, angiography, CT, or reoperation. However, subsequent management remains controversial. Given that early PPH is often attributed to technical failure or underlying coagulopathy, most surgeons advocate for reoperation, whereas delayed PPH is usually secondary to complications, such as abscess formation, vessel erosions, pancreatic fistulas, ulcerations at anastomosis sites, or pseudoaneurysm development. For the treatment of delayed hemorrhage, some groups advocate for operative intervention, whereas others support an interventional or endoscopic approach whenever possible (12-14). In general, accessing or controlling hemorrhages is difficult because of pancreatic leakage or infection in the operative field for reoperation. In our case, a non-operative approach to control the hemorrhage was initially given high priority. However, operative intervention was undertaken eventually.

Given the high mortality associated with PPH, identifying the sources of a hemorrhage is valuable. PPH may originate from the following (15): (I) arterial or venous vessels; (II) anastomotic stoma (gastroenteric, jejunojejunal, or pancreaticoenteric); (III) resection areas (e.g., pancreas stump or retroperitoneum); (IV) gastric/duodenal ulcer or diffuse gastritis; (V) eroded and ruptured pseudoaneurysms; or (VI) hemobilia from previously placed endobiliary stents. Dumitru et al. reported an uncommon cause of delayed hemorrhage after PD caused by a splenic artery pseudoaneurysm (16). To our knowledge, this is the first case report of output jejunal loop intussusception in the stomach that consequently caused PPH after PD.

The identification of patients who are at risk for PPH is clinically meaningful. A previous study reported that age, postoperative pancreatic fistulas (POPFs), and nutritional risk indexes are risk factors for PPH (17). Another study conducted multivariate modeling and identified several risk factors, including advanced age, increased body mass index, intraoperative transfusion, portal venous and multivisceral resections, and POPFs, for severe PPH (18). Izumo et al. found that the absence of diabetes mellitus and POPFs are risk factors for PPH in patients who underwent PD (19). In contrast to patients in these studies, our patient lacked POPFs.

Output jejunal loop intussusception in the stomach after PD is rare. Prolonged pneumoperitoneum caused by using the da Vinci robot might be one of the reasons for the intussusception of the output loop in the stomach in our case. Repeated vomiting and increased positive pressure within the abdomen might be other reasons.

Conclusions

This is the first case report of output jejunal loop intussusception in the stomach that consequently caused PPH after RAPD for pancreatic head cancer.

Acknowledgments

Funding: This study was supported by the Big Data Project of Xiangya Medical School, Central South University, the grants from the Innovation and Development Project of Development and Reform Commission of Hunan Province {No. [2019]875}, the Scientific and Technological Progress and Innovation Project of Communications Department of Hunan Province {No. [2018]234(201835)}.

Footnote

Reporting Checklist: The authors have completed the CARE reporting checklist. Available at http://dx.doi.org/10.21037/jgo-20-207

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/jgo-20-207). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this study and any accompanying images.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
