Response to hepatic arterial infusion chemotherapy combined with camrelizumab and targeted therapy in advanced primary hepatic neuroendocrine carcinoma: a case report and literature review

Introduction

Neuroendocrine neoplasms (NEN) are a particularly rare group of malignant tumors which include well-differentiated neuroendocrine tumors (NET) and poorly-differentiated neuroendocrine carcinoma (NEC). Only a few case reports have described primary hepatic NEC and the existence of this entity is uncertain given the possibility of metastatic NEC to the liver of unknown primary (1-3).

The standard of care for advanced NEC is systemic platinum-based chemotherapy. The role of immunotherapy is still uncertain and studies are evaluating first-line combination of checkpoint inhibitors combined with chemotherapy. Here, we describe a patient with advanced primary hepatic neuroendocrine carcinoma (PHNEC) and lymph node metastasis who was successfully treated with an unconventional regimen consisting of hepatic arterial infusion chemotherapy (HAIC) combined with camrelizumab and apatinib. We present this article in accordance with the CARE reporting checklist (available at https://jgo.amegroups.com/article/view/10.21037/jgo-24-571/rc).

Case presentation

In March 12, 2021, a 53-year-old male visited the Fifth Affiliated Hospital of Guangxi Medical University (Guangxi, China) for persistent upper right abdominal pain. Laboratory testing showed that serum α-fetoprotein (AFP), protein induced by vitamin K absence or antagonist-II (PIVKA-II), and serum carbohydrate antigen 19-9 (CA19-9) levels were normal and that hepatitis C virus antibody (HCV Ab) was negative; however, hepatitis B virus surface antigen (HBsAg) was positive, and the liver background was cirrhotic. Contrast-enhanced abdominal computed tomography (CT) showed multiple masses located in the right lobe of the liver, with the largest one measuring about 9.2 cm × 6.3 cm × 8.8 cm in diameter. CT revealed multiple well-circumscribed, heterogeneous, and hypodense masses in the right liver lobe during the plain scan phases. CT further revealed masses with significant heterogeneous contrast enhancement during the arterial phase, with the enhancement continuing during the portal phases (Figure 1). In magnetic resonance imaging (MRI), the masses were hypointense during the T1-weighted imaging phase and had a significant high-intensity area during the T2- and diffusion-weighted imaging phases. On enhanced MRI, the solid portions of these masses showed significant enhancement in the early arterial phase, and the masses remained significantly enhanced in the portal venous phase. CT and MRI both detected multiple enlarged portal lymph nodes with significant heterogeneous enhancement, with the largest node measuring about 5.6 cm ×7.2 cm in size (Figure 2). The pathological findings of the biopsy mass specimen from the right liver lobe suggested a malignant neoplasm that had originated from a neuroendocrine cell type. The pathological findings suggested that the intermediate-sized tumor cells were arranged in nests with uniform round or oval nuclei, a moderate amount of eosinophilic cytoplasm, and frequent mitosis. There were no areas of necrosis. Histological and immunohistochemical examinations revealed positive staining for clusters of differentiation 56 (CD56), cytokeratin (CK) 8/18 and synaptophysin and suggested a malignant neoplasm that had originated from a neuroendocrine cell type. The tumor cells were negative for chromogranin A and hepatocyte 1, and the tumor had a Ki-67 index of 80% (Figure 3). The results of immunohistochemical staining confirmed NEC of the liver. Additionally, endoscopic, colonoscopy, CT and MRI were used to exclude extrahepatic primary NEC.

Figure 1 CT images before initiation of six courses of HAIC showed multiple well-circumscribed, heterogeneous, hypodense liver masses. (A) The largest was located in the right lobe of the liver and measured about 9.2 cm × 6.3 cm × 8.8 cm in diameter. Masses with significant contrast enhancement during the (B) arterial and (C) portal phases. A massive portal lymph nodes lesion appeared as (D) hypodense on unenhanced CT scanning. (E) heterogeneous arterial hyperenhancement and (F) washout in the portal phases after contrast. CT, computed tomography; HAIC, hepatic arterial infusion chemotherapy.

Figure 2 MR images before the initiation of six courses of HAIC: the largest mass size of 9.2 cm × 6.3 cm × 8.8 cm in the right lobe of liver, with a massive portal lymph node lesion measuring 5.6 cm × 7.2 cm in size. (A,D) Transverse T1-weighted imaging. (B,E) Contrast-enhanced dynamic T1-weighted arterial phase and (C,F) delayed phase imaging. (G,I) Transverse T2-weighted and (H,J) transverse diffusion-weighted imaging. MR, magnetic resonance; HAIC, hepatic arterial infusion chemotherapy.

Figure 3 Histopathology. Hematoxylin and eosin staining at ×200 (A) and ×400 (B). Immunohistochemistry was positive for the NEC markers (D) Syn, (F) Ki-67, (G) CD56, and (H) CK8/18, and negative for (C) CgA and (E) hepatocyte 1 in primary hepatic NEC tissues (×400). CgA, chromogranin A; Syn, synaptophysin; CK, cytokeratin; NEC, neuroendocrine carcinoma.

On admission, the patient was alert and conscious, with a height of 165 cm and a weight of 60 kg. Physical examination showed no signs of jaundice.

The patient underwent HAIC with the modified fluorouracil and oxaliplatin (mFOLFOX) (oxaliplatin 85 mg/m², leucovorin 400 mg/m², and fluorouracil 2,500 mg/m²; continuous intra-arterial infusion over 46 hours). A microcatheter was inserted through the hepatic arterial catheter, and then angiography was performed (Figure 4). The microcatheter eventually was placed in the tumor-feeding artery of the liver. The extracorporeal section of the catheter was covered with sterile medical gauze and fastened on the skin of the thigh using bandages. Chemotherapy with an mFOLFOX regimen was administered when the patient returned to the ward.

Figure 4 Angiogram showing multiple masses in the right lobe of the liver and a massive portal lymph node.

HAIC was performed every 3 weeks until 6 courses were completed.

The patient received camrelizumab at a fixed dose of 200 mg intravenously within 7 days after the start of HAIC. Meanwhile, the patient continued to receive oral apatinib at a dose of 250 mg once daily. After six courses of HAIC combined with camrelizumab and continued oral apatinib, the patient showed no clinical symptoms when he was rehospitalized. The levels of tumor markers including AFP (normal range: 0–8.04 ng/mL), CA19-9 (normal range: 0–37 U/mL), and PIVKA-II (normal range: 0–40 AU/mL) were negative. Liver and renal functions were normal. CT showed a marked decrease in the size of the largest liver mass and partial portal lymph nodes, without obvious new metastases, indicating a partial response of the PHNEC (Figure 5). MRI showed that the size of the intrahepatic lesions decreased, similarly to that shown on CT. MRI also indicated that the multiple portal lymph nodes had decreased in size compared with shown in the previous MR examination (Figure 6).

Figure 5 CT images after six courses of HAIC: the size of the largest liver mass and partial portal lymph nodes was markedly decreased. Postcontrast CT image of the (A,D) arterial phase, (B,E) portal venous phase, and (C,F) delayed phase. CT, computed tomography; HAIC, hepatic arterial infusion chemotherapy.

Figure 6 MR images after six courses of HAIC: (A,D) transverse T1-weighted imaging, contrast-enhanced dynamic T1-weighted imaging at the (B,E) arterial phase and (C,F) delayed phase, and (G,I) transverse T2-weighted and (H,J) transverse diffusion-weighted imaging. MR, magnetic resonance; HAIC, hepatic arterial infusion chemotherapy.

After six cycles of HAIC, regular examinations were conducted for follow-up. The patient was treated with camrelizumab combined with apatinib. On November 13, 2021, apatinib was changed to anlotinib.

At the fourth month of follow-up after six cycles of HAIC, the reexamination indicated tumor progression, with an approximately 3.4 cm × 4 cm sized tumor metastasis in the right liver lobe (S6), a slight annular enhancement surrounding tumor on enhanced CT, and slight hypointensity during the hepatobiliary phase (Figure 7).

Figure 7 CT images after 4 months of follow-up after 6 cycles of HAIC. A new tumor appeared in the (A1,A2) unenhanced CT scanning phase, the liver postcontrast CT image of the (B1,B2) arterial phase and (C1,C2) portal venous phase. CT, computed tomography; HAIC, hepatic arterial infusion chemotherapy.

The routine reexaminations after two cycles of HAIC treatment showed that both the original and new lesions had shrunk (Figure 8). The patient was administered camrelizumab and anlotinib regularly.

Figure 8 CT images of the tumor recurred after two cycles of HAIC. The primary lesion was smaller than that before the (A1,A2) unenhanced CT scanning phase, the (B1,B2) arterial phase and (C1,C2) portal venous phase. CT, computed tomography; HAIC, hepatic arterial infusion chemotherapy.

On March 1, 2023, the last follow-up CT showed that the primary lesion measured 3.2 cm × 1.5 cm × 2.2 cm in size, with slightly enhanced intrahepatic nodules during the enhanced arterial phase. The enhancement was reduced in the portal vein phase and the delayed phase, and the recurrent lesion had disappeared (Figure 9). On March 2, 2023, camrelizumab was discontinued after 2 years of use. At the time of writing, the patient is regularly taking antitumor therapy with anlotinib alone (Figure 10). All procedures performed in this study were in accordance with the ethical standards of the national research committees and with the Declaration of Helsinki (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Figure 9 CT images at the last follow-up. The primary lesion was smaller than that before the (A1,A2) unenhanced CT scanning phase, the (B1,B2) arterial phase and (C1,C2) portal venous phase. (D1,D2) The size of the largest liver mass and partial portal lymph nodes was markedly decreased. CT, computed tomography.

Figure 10 The timeline of patient’s treatment history. HAIC, hepatic arterial infusion chemotherapy.

Discussion

Primary NEC primarily can arise throughout the body including pancreas, gastrointestinal tract, and bronchopulmonary tract, especially lung. Primary hepatic neuroendocrine tumors (PHNETs) are a rarity and represent about 0.3% of all NETs, among PHNECs are extremely rare, with only about 90 cases having been reported in the English-language literature (3). The PHNEC patients usually presented a functional digestive disorder accompanied by abdominal discomfort. Several case reports have described primary hepatic NEC, but distinguishing this entity from metastatic NEC to the liver of unknown primary is challenging. There is also a lack of distinctive radiological features for PHNECs, and thus they are often misdiagnosed (1,4,5). Clinically, it is challenging to distinguish PHNECs from hepatocellular carcinoma (HCC) or intrahepatic cholangiocarcinoma (6) before pathologic evaluation of a resected specimen by biopsy or surgery. A previous study showed that the positivity rates for SYN, CGA, and CD56 of PHNEC are >80% (7). In these situations, pathologic evaluation by liver biopsy may be valuable for the guidance of definitive diagnosis and oncological treatment. As we known, the origin of neuroendocrine cells can be traced back to gastrointestinal stem cells. Somatostatin receptors is association with tumor protein synthesis, hormone secretion, and proliferation of neuroendocrine tumors. The angiogenesis and metabolic in NEN rely on the upregulation of the mammalian target of rapamycin. Furthermore, proangiogenic factors such as vascular endothelial growth factor, angiopoietin, and fibroblast growth factor, are may induce the tumorigenesis of NETs. Therefore, inhibition the angiogenesis may it possible to block the proliferation and growth of NENs. According to previous study, we found that the infiltration of immune-related cells can also build an immunosuppressive microenvironment for the progression of NETs (8). Interestingly, some studies have found that NECs have features of high TMB and programmed cell death ligand 1 (PD-L1)-positive expression, which indicating promising responsiveness to immune checkpoint inhibitors (ICIs) (9-11).

The management of NECs remains controversial. There are standard drugs for PHNEC according to the consensus guidelines for NEC proposed by the North American Neuroendocrine Tumor Society, including cisplatin, carboplatin and etoposide. A study has indicated that HAIC may significantly improve the overall survival in patients with advanced HCC and provide better tumor control compared to transarterial chemoembolization (TACE) or transarterial embolization treatment, producing only mild side effects (12). Another study also indicated HAIC to be superior to TACE for the treatment of patients with unresectable ICC (13). As aforementioned, some studies have shown immunogenic and promising responsiveness to ICIs in NECs with a high tumor mutational burden (TMB) rate and high frequency of positive PD-L1 expression (9-11). Additionally, some trials have showed the efficacy and manageable toxicity of ICIs in refractory high-grade NETs (14-16). Currently, a phase II study is conducted to investigate the therapeutic potential of camrelizumab plus chemotherapy for advanced GEP-NEC (17). Apatinib has shown potentially positive outcomes in the treatment of gastric cancer (18). A recent case report indicated that the combined treatment (camrelizumab and apatinib) could substantially improve the NET G2 conditions-associated liver metastasis (19). A study had demonstrated that the addition of an anti-PD-L1 antibody to the chemotherapy backbone raised 3-year OS from 5.8% to 17.6% in small-cell lung cancer patients (20). A previous study based on patients with PD-L1-positive NETs showed that pembrolizumab treatment yielded an objective response rate (ORR) of 6.3% for patients with well- or moderately-differentiated pancreatic neuroendocrine tumors (16). Additionally, a multi-center phase Ib trial indicated a comparable response rate between the well-differentiated NET subgroup and poorly-differentiated NEC subgroup when 40 NEN patients were treated with anti-programmed cell death protein 1 (anti-PD-1) therapy (ORR: 18.7% vs. 25.0%) (21). Two placebo controlled phase 3 trials (NCT02588170 and NCT02589821) have demonstrated that those treated with tyrosine kinase inhibitors using surufatinib in extrapancreatic and PanNETs improved PFS (22,23).

Our study was the first to evaluate the efficacy of HAIC combined with a PD-1 inhibitor and targeted antiangiogenic therapy in patients with PHNEC. Administration of intrahepatic chemotherapy using a platinum-based regimen (e.g., FOLFOX) may represent an alternative to systemic therapy in patients with PHNEC with minimal or absent extra-hepatic disease.

Conclusions

We present the first report of an extremely rare case of PHNEC treated with HAIC combined with camrelizumab and apatinib. Presently, liver resection remains the only curative treatment for patients with PHNECs. However, for patients with unresectable PHNECs, the optimal treatment is controversial; nonetheless, HAIC combined with camrelizumab and targeted therapy may be a safe and effective treatment.

Acknowledgments

Funding: None.

Footnote

Reporting Checklist: The authors have completed the CARE reporting checklist. Available at https://jgo.amegroups.com/article/view/10.21037/jgo-24-571/rc

Peer Review File: Available at https://jgo.amegroups.com/article/view/10.21037/jgo-24-571/prf

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://jgo.amegroups.com/article/view/10.21037/jgo-24-571/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in this study were in accordance with the ethical standards of the national research committees and with the Declaration of Helsinki (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Huang YQ, Xu F, Yang JM, et al. Primary hepatic neuroendocrine carcinoma: clinical analysis of 11 cases. Hepatobiliary Pancreat Dis Int 2010;9:44-8. [PubMed]
2. Sotiropoulos GC, Charalampoudis P, Delladetsima I, et al. Surgery for giant primary neuroendocrine carcinoma of the liver. J Gastrointest Surg 2014;18:839-41. [Crossref] [PubMed]
3. Fernández-Ferreira R, Romero-López U, Robles-Aviña JA, et al. Primary Hepatic Neuroendocrine Carcinoma with Metastasis to the Mesentery: A Case Report. Case Rep Oncol 2023;16:681-97. [Crossref] [PubMed]
4. Huang K, Lan Z, Chen W, et al. Hepatectomy and pneumectomy combined with targeted therapy for primary hepatic neuroendocrine carcinoma: Case report and review of the literature. Front Surg 2022;9:920276. [Crossref] [PubMed]
5. Huang HF, Jin PP, Yang HJ, et al. Primary Hepatic Neuroendocrine Tumor Mimicking Ruptured Hepatocellular Carcinoma with AFP Elevation: A Case Report and Literature Review. Onco Targets Ther 2020;13:975-9. [Crossref] [PubMed]
6. De Raffele E, Mirarchi M, Cuicchi D, et al. Simultaneous colorectal and parenchymal-sparing liver resection for advanced colorectal carcinoma with synchronous liver metastases: Between conventional and mini-invasive approaches. World J Gastroenterol 2020;26:6529-55. [Crossref] [PubMed]
7. Qiu MJ, Chen YB, Bi NR, et al. Comparative Clinical Analysis of Gastroenteropancreatic Neuroendocrine Carcinomas with Liver Metastasis and Primary Hepatic Neuroendocrine Carcinomas. Dis Markers 2018;2018:9191639. [Crossref] [PubMed]
8. da Silva A, Bowden M, Zhang S, et al. Characterization of the Neuroendocrine Tumor Immune Microenvironment. Pancreas 2018;47:1123-9. [Crossref] [PubMed]
9. Peifer M, Fernández-Cuesta L, Sos ML, et al. Integrative genome analyses identify key somatic driver mutations of small-cell lung cancer. Nat Genet 2012;44:1104-10. [Crossref] [PubMed]
10. Vijayvergia N, Boland PM, Handorf E, et al. Molecular profiling of neuroendocrine malignancies to identify prognostic and therapeutic markers: a Fox Chase Cancer Center Pilot Study. Br J Cancer 2016;115:564-70. [Crossref] [PubMed]
11. Kim ST, Ha SY, Lee S, et al. The Impact of PD-L1 Expression in Patients with Metastatic GEP-NETs. J Cancer 2016;7:484-9. [Crossref] [PubMed]
12. Hu J, Bao Q, Cao G, et al. Hepatic Arterial Infusion Chemotherapy Using Oxaliplatin Plus 5-Fluorouracil Versus Transarterial Chemoembolization/Embolization for the Treatment of Advanced Hepatocellular Carcinoma with Major Portal Vein Tumor Thrombosis. Cardiovasc Intervent Radiol 2020;43:996-1005. [Crossref] [PubMed]
13. Cai Z, He C, Zhao C, et al. Survival Comparisons of Hepatic Arterial Infusion Chemotherapy With mFOLFOX and Transarterial Chemoembolization in Patients With Unresectable Intrahepatic Cholangiocarcinoma. Front Oncol 2021;11:611118. [Crossref] [PubMed]
14. Patel SP, Othus M, Chae YK, et al. A Phase II Basket Trial of Dual Anti-CTLA-4 and Anti-PD-1 Blockade in Rare Tumors (DART SWOG 1609) in Patients with Nonpancreatic Neuroendocrine Tumors. Clin Cancer Res 2020;26:2290-6. [Crossref] [PubMed]
15. Strosberg J, Mizuno N, Doi T, et al. Efficacy and Safety of Pembrolizumab in Previously Treated Advanced Neuroendocrine Tumors: Results From the Phase II KEYNOTE-158 Study. Clin Cancer Res 2020;26:2124-30. [Crossref] [PubMed]
16. Mehnert JM, Bergsland E, O'Neil BH, et al. Pembrolizumab for the treatment of programmed death-ligand 1-positive advanced carcinoid or pancreatic neuroendocrine tumors: Results from the KEYNOTE-028 study. Cancer 2020;126:3021-30. [Crossref] [PubMed]
17. Li X, Ma Q, Chang C, et al. First-line treatment of camrelizumab combined with chemotherapy in advanced gastroenteropancreatic neuroendocrine carcinoma: Study protocol for a prospective, multicenter, phase II study. Front Oncol 2022;12:958905. [Crossref] [PubMed]
18. Wang X, Yu J, Yang M, et al. Safety and effectiveness of apatinib in patients with previously treated metastatic gastric cancer: a sub-analysis from the real-world study of apatinib for gastric cancer treatment (AHEAD-G202). Am J Cancer Res 2020;10:987-96. [PubMed]
19. Qi R, Yang W, Zhu S, et al. Transcatheter arterial chemoembolization of apatinib and camrelizumab (SHR1210) against liver metastasis from hepatic neuroendocrine tumor: a case report. Front Oncol 2024;14:1278340. [Crossref] [PubMed]
20. Paz-Ares L, Chen Y, Reinmuth N, et al. Durvalumab, with or without tremelimumab, plus platinum-etoposide in first-line treatment of extensive-stage small-cell lung cancer: 3-year overall survival update from CASPIAN. ESMO Open 2022;7:100408. [Crossref] [PubMed]
21. Lu M, Zhang P, Zhang Y, et al. Efficacy, Safety, and Biomarkers of Toripalimab in Patients with Recurrent or Metastatic Neuroendocrine Neoplasms: A Multiple-Center Phase Ib Trial. Clin Cancer Res 2020;26:2337-45. [Crossref] [PubMed]
22. Xu J, Shen L, Zhou Z, et al. Surufatinib in advanced extrapancreatic neuroendocrine tumours (SANET-ep): a randomised, double-blind, placebo-controlled, phase 3 study. Lancet Oncol 2020;21:1500-12. [Crossref] [PubMed]
23. Xu J, Shen L, Bai C, et al. Surufatinib in advanced pancreatic neuroendocrine tumours (SANET-p): a randomised, double-blind, placebo-controlled, phase 3 study. Lancet Oncol 2020;21:1489-99. [Crossref] [PubMed]
